Orbit 1-2 HP Irrigation Pump Start Relay

Item: #761359

Model : #57009

UPC #00046878570092

$52.99

In-store price may vary from online price. Not all products available at all stores.

SALE

Caption goes here.

$52.99

In-store price may vary from online price. Not all products available at all stores.

Free Ship-to-Store

JETSONS6032 Huguenard Rd
FORT WAYNE, IN 46818 US

Estimated pickup day: 12/9/2025

Ship to Address

The pump start relay is engineered to synchronize an irrigation pump with an irrigation/sprinkler controller.
It is effective for a variety of water sources, including wells, ponds, and bore holes. 24 VAC leads connect the controller to the relay.
It is capable of actuating 120 VAC pumps up to 1HP and 230 VAC pumps up to 2HP.
The enclosure is constructed from durable water-resistant plastic.
The pump start relay is compatible with irrigation controllers from Orbit, Hydro-Rain, and other major brands.
For outdoor irrigation use with cold water only.

For automatically synchronizing an irrigation pump and sprinkler controller
Durable ABS enclosure stands up to the elements and ensures long life
Controls 120 VAC pumps up to 1HP and 230 VAC pumps up to 2HP
Compatible with 24 VAC irrigation controllers from Orbit, Hydro-Rain, and other major brands
